Prefab Steel Structure Warehouse Building Metal Frame Construction

500 square meters
MOQ
USD 40-80 per square meter
Price
Prefab Steel Structure Warehouse Building Metal Frame Construction
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Steel Structure Warehouse
Standard: GB Standard
Bolt Accessories: Foundation Bolt & High -Strength Bolts & General Bolt
Main Structure: C Beam & H Beam
Door And Window: According To Customer Request
Wall Cladding: Steel Color Sheet, Sandwich Panel
Application: Steel Warehouse
OEM/ODM: YES
High Light:

OEM Steel Structure Warehouse

,

ODM Steel Structure Warehouse

,

Prefab Steel Frame Construction

Basic Infomation
Place of Origin: China
Brand Name: QCX
Certification: ISO 9001, CE
Model Number: Steel Frame Structure
Payment & Shipping Terms
Packaging Details: Steel components are packaged with steel pallets at the factory with the coding number, which is convenient for customers to unload
Delivery Time: 30~35 days
Payment Terms: L/C, T/T
Supply Ability: 2000 tons per month
Product Description

Prefab Steel Structure Warehouse Building Metal Frame Construction

Product Description:


Light steel structure building is a new type of building structure system, which is formed by the main steel framework such as H-section, Z-section steel components, roof and walls (a variety of panels) and other components such as windows and doors. Light steel structure building is widely used in warehouses, workshops, large factories, and so on.


Compared with the traditional concrete structure building system, the light steel structure projects have a series of advantages, such as large span, low demands of base structure, strong seismic and wind resistance, beautiful appearance, shorter construction cycle, strong corrosion resistance, non-polluted, low maintenance costs and so on. Therefore it is more and more popular with the customers. It is mainly used for large-span structures, workshops, warehouses, office buildings, large supermarkets, logistics warehouses, showrooms, hangar, etc.


Because of the diversification of steel structure material and the flexible design, the light steel structure projects can better meet customers' demands for space structures, and reasonable economy.


Scope of Application

It is widely used in large-span steel structure housing, factories, storage, office buildings, gymnasiums, hangars and so on.It is
suitable for single-storey long-span buildings, but also for multi-storey buildings. and other areas


Product specifications


1. Main Steel Q355, Q235, Q355B, Q235B etc.
2. Column & Beam Welded or Hot rolled H-section
3. Connection method Welding connection or Bolt connection
4. Wall & Roof EPS,Glass wool, Rock wool, PU sandwich, corrugated steel sheet
5. Door Rolled up door or Sliding door
6. Window Plastic steel or Aluminum alloy window
7. Surface Hot dip galvanized or painted
8. Crane 5MT, 10MT, 15MT and more






















Prefab Steel Structure Warehouse Building Metal Frame Construction 0
C
ompany profile:


Qingdao Qianchengxin Construction Technology Co, Ltd. was established in 2014. lt is a high-tech, diversified and export-oriented large-scale international private enterprise integrating R&D, design, production, installation and construction at home and abroad, and technical services.
Qian Chengxin has the qualification certificate of China's overseas contracted project management issued by the Ministry of Commerce of China, CE certification [EN1090 certificatel), ISO9001 certificate, etc, and has carried out long-term cooperation with countries along the "Belt and Road". The current products and construction services have been exported to more than 50 countries around the world, including Asia, Africa, North and South America. ln addition. branches have been established in Mozambigue and Angola, which can undertake steel structure installation projects in Africa


Production capacity:

The company can produce more than 30 kinds of series products with different structures and specifications. It has complete processing and manufacturing equipment and strong installation capabilities. It can supply a full set of materials required for steel structure construction projects, and provide all installation services and technical consultation.
The company has 2 composite board production lines with an annual output of more than 1 millionmeters; 5 color steel plate production lines with an annual output of 2 million meters; 2 H-beam CNC production lines with an annual output of 20000 tons: One C-beam production line with an annual output of 2500 tons; One Z-Beam steel production line with an annual output of 2,000 tons.
in addition to various section-steel products, it can also manufacture color steel sheets, compositepanels, lighting panels, ventilators, etc.

Prefab Steel Structure Warehouse Building Metal Frame Construction 1

Services:

We can provide you with a complete service from quote, design, manufacture, etc, according to your requirements & drawing. The manufacture procedure including drilling, rust-removing, shot blasting, nondestructive detecting, painting and so on.
When designing and building any structure, there are many factors to consider such as safety, strength, cost and maintenance, etc. The materials must also be sustainable and environmental, thus to make a contribution towards the sustainability of the project itself.
chooseing the correct material for the task is vital, and this choice is now influenced by economic and environmental pressures that were not important several years ago. Save the tree and our earth, please choose light gauge steel framed house. Our technical and R&D support are ready to help you chose the correct grade of steel for each application, which can result in the most cost effective solutions for today’s architecture, building and construction requirements.


Packing and loading:


Our technical team will do the economical packing plan for clients, calculate the quantity of steel structure materials accurately and use the min. quantity of containers, to save the shipping freight for clients.
When packing we use the pallets according to container's size, to improve the loading unloading efficency.


Could you tell me your requirement for your steel structure project?

Basic design requirements and design Load,
1. Project site location;
2. Overall dimension (length*width*eave height in meters);
3. Mezzanine or not? How many kgs of load per square meter on mezzanine?
4. Single-layer steel sheet wall or sandwich panel wall;
5. Snow load if applicable;
6. Wind speed/load;
7. Interior column allowed or not;
8. Overhead crane needed or not, capacity?;
9. Any other particular requirements?
