Light Gauge Steel Frame Construction Portal Frame Steel Structure Warehouse

500 square meters
MOQ
USD 35-55 per square meter
Price
Light Gauge Steel Frame Construction Portal Frame Steel Structure Warehouse
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Steel Structure Warehouse
Type: Light Steel
Purlin: Hot Dipped Galvanized C Z Purlin
Surface Treatment: Hot Dip Galvanized And Painted
Grade: Q235B,Q355B
Tolerance: ±1%
Wall Clading: Steel Sheet Or Sandwich Panel (EPS, PU, Glass Wool,Rock Wool)
Use Age: Over 50years
Basic Infomation
Place of Origin: China
Brand Name: QCX
Certification: ISO 9001, CE
Model Number: Steel Frame Structure
Payment & Shipping Terms
Packaging Details: Steel components are packaged with steel pallets at the factory with the coding number, which is convenient for customers to unload
Delivery Time: 25~30 days
Payment Terms: L/C, T/T
Supply Ability: 2000 tons per month
Product Description

Light Gauge Steel Frame Construction Portal Frame Steel Structure Warehouse


Product Description


The Prefab steel structure warehouse is custom-designed to meet any industrial or commercial storage needs. This steel structure warehouse building supports any crane with different lifting capacities and can accommodate vehicular traffic on the ground level. The warehouse building is specifically designed for large and medium-sized warehouses. By enclosing the main steel frame with wall and roof, it can provide an enclosed structure for indoor storage of goods. A mezzanine area can be used as an office to meet the needs of material transportation, storage and processing.



Light Gauge Steel Frame Construction Portal Frame Steel Structure Warehouse 0

Characteristics of steel structure warehouse


Steel structure warehouse is more economical than conventional buildings. The construction process is relatively simple; the prefabricated steel structure’s construction process is usually not as easy to delay the construction period of other buildings. All drilling, cutting, and welding are carried out in the factory, and then the parts are transported to the construction site for installation. Since only the parts are assembled on-site, there is almost no other cost increase.

Moreover, the technical requirements for the assembly of this prefabricated steel warehouse are not high. Almost anyone can do it, thus reducing labor costs and saving time.

Steel structure warehouse is a prefabricated building material. It has high strength and easy assembly so it can be assembled quickly. The construction period of the steel warehouse is generally much shorter than conventional construction. Professional engineers design the steel structure warehouse according to different needs, saving you a lot of time on construction and greatly reducing your cost.



Light Gauge Steel Frame Construction Portal Frame Steel Structure Warehouse 1


Product Specifications


Dimension Length x Width x Eave height/ Ridge height
Frame type Portal frame, multi-story frame
Main frame Hot-rolled or Welded H beam and column, Q355B steel
Bracing components Tie bar, staying bar, Horizontal bracing, Column bracing
Cladding system Corrugated color steel sheet, sandwich panel with glass wool, rock wool,PU,EPS insulation
Accessory Ridge tile, trim, Gutter, Down pipe,skylight
Door Sliding door, Roll up door, industrial section door, swing door
Window PVC window, aluminum window, metal louver























Company profile

Qingdao Qianchengxin Construction Technology Co, Ltd. was established in 2014. lt is a high-tech, diversified and export-oriented large-scale international private enterprise integrating R&D, design, production, installation and construction at home and abroad, and technical services.

Qian Chengxin has the qualification certificate of China's overseas contracted project management issued by the Ministry of Commerce of China, CE certification [EN1090 certificatel), ISO9001 certificate, etc, and has carried out long-term cooperation with countries along the "Belt and Road". The current products and construction services have been exported to more than 50 countries around the world, including Asia, Africa, North and South America. ln addition. branches have been established in Mozambigue and Angola, which can undertake steel structure installation projects in Africa
Light Gauge Steel Frame Construction Portal Frame Steel Structure Warehouse 2

Production process
Light Gauge Steel Frame Construction Portal Frame Steel Structure Warehouse 3


Qualification certificates:

Light Gauge Steel Frame Construction Portal Frame Steel Structure Warehouse 4

Services:

We can provide you with a complete service from quote, design, manufacture, etc, according to your requirements & drawing. The manufacture procedure including drilling, rust-removing, shot blasting, nondestructive detecting, painting and so on.
When designing and building any structure, there are many factors to consider such as safety, strength, cost and maintenance, etc. The materials must also be sustainable and environmental, thus to make a contribution towards the sustainability of the project itself.
chooseing the correct material for the task is vital, and this choice is now influenced by economic and environmental pressures that were not important several years ago. Save the tree and our earth, please choose light gauge steel framed house. Our technical and R&D support are ready to help you chose the correct grade of steel for each application, which can result in the most cost effective solutions for today’s architecture, building and construction requirements.


Packing and loading:


Our technical team will do the economical packing plan for clients, calculate the quantity of steel structure materials accurately and use the min. quantity of containers, to save the shipping freight for clients.

When packing we use the pallets according to container's size, to improve the loading unloading efficency.

Light Gauge Steel Frame Construction Portal Frame Steel Structure Warehouse 5
Fixed packing, loading, transportation, unloading the matters needing attention


(1) The lifting large there must be a person responsible for the use of fixture, suitable, strictly abide by the rules of lifting, to prevent the   occurrence of vibration, impact, deformation or damage, fall in the hoisting process.


(2) At the time of loading, there must be a special supervision, check car number and packing, the car pile up securely, and to increase the     necessary binding component loosening, prevent the loss.


(3) Remained stable in the transport process, the vehicle at the time of shipment, on the long, wide, high object transport, must be trained pilots,     escort personnel responsible for, and mark is arranged on a vehicle.


(4) No rough handling, loading and unloading personnel handling, weight, size should be familiar with the components, and check the horse sling,  rigging, prevent accidents.


(5) The member to the construction site, timely organization of unloading, stacking area.


(6) The crawler crane carrying member, should pay attention to the surrounding terrain, air condition, prevent the crawler crane overturning and  component collision.



FAQ

Q1: You are manufacture factory or trading company?
A: We are direct manufacture for steel structure buildings. we have rich experiance of steel structure designing,manufacturing, processing and installation.


Q2: Is your price competitive with other companies?
A: Our business goal is to give you the best price with same quality and best quality with the same price. We will try our best to reduce your cost.


Q3: Do you offer service for installation?
A: We will give detailed installation drawings and video for free. And if you need, we could send engineers as installation director even a team.


Q4: Do you accept container loading inspection?
A: You are welcomed to send an inspector, not only for the container loading, but any time during the production time.


Q5: Do you offer designing service for us?
A: Yes, we have experienced design team,and we can design full solution drawings as your requirements.


Q6: What is the delivery time?
A: Delivery time depends on order quantities. Generally, the delivery time will be 30 days after receiving deposit.


Q7: How can you get a quotation for your projects?
A: You can chat with us anytime or you can just fill out our questionnaire and send back to us. We will give you the best quotation asap.
