Easy Install Steel Structure Warehouse For Industrial Construction With Aluminum Windows

500SQM
MOQ
$35~$55 per sqm
Price
Easy Install Steel Structure Warehouse For Industrial Construction With Aluminum Windows
Features Gallery Product Description Request A Quote
Features
Specifications
Purlin: C/Z-Section Steel
Processing Service: Bending, Welding, Decoiling, Cutting, Punching
Wall: Sandwich Panel/Color Steel Sheet
Material: Q355B/ Q235B Steel
Doors: Roller Shutter/Swing/Sliding
Size: Customized
Insulation: Optional
Column: Hot Rolled/Welded H-Section Steel
High Light:

Industrial Q235B Steel Structure Warehouse

,

Construction Q355B Steel Structure Warehouse

,

CE Prefabricated Metal Warehouse

Basic Infomation
Place of Origin: China
Brand Name: QCX
Certification: CE/ ISO9001
Model Number: Steel structure warehouse
Payment & Shipping Terms
Packaging Details: According to packinglist
Delivery Time: 30~45 days
Payment Terms: T/T,L/C
Supply Ability: 3500Tons/Month
Product Description

Easy Install Steel Structure Warehouse For Industrial Construction With Aluminum Windows

Product Description:



A steel structure warehouse is a type of metal warehouse that is commonly used to store goods and materials. It is designed and constructed with a steel frame, making it strong, durable, and able to withstand harsh weather conditions. The steel structure warehouse is an ideal solution for businesses that require large storage spaces for their products.



Main Parameters Steel Structure Warehouse


Length: The total length of the plant needs to be determined. Whether there is a requirement for the column spacing, the column spacing is generally 6m, but it can also be 7.5m, 9m, or 12m;

Span: generally 9-36m, with 3m as a multiple, when the span is large, it is necessary to determine the design of several spans;

Height: indoor floor to the intersection of steel column axis and steel beam axis (clear height of plant), without lifting the crane should be 4.5-9m; when there is a crane, the specific model and lifting height of the crane should be determined;
Whether the roof and walls need to be insulated.


Main Components


The main components of steel workshop include steel column, steel beam, wind-proof column and crane beam.

 Steel column: It can be a H-shaped steel column with a constant cross-section or a H-shaped steel column with a variable cross-section.
It is easy to manufacture, safe and reliable, and the main material is Q235B or Q345B.
When the horizontal span of the steel workshop building does not exceed 15m and the column height does not exceed 6m, the steel column should be made of H-shaped steel with equal cross section.
When the span of the factory building is greater than 15m and the column height exceeds 6m, the variable-section steel column should be adopted.
Easy Install Steel Structure Warehouse For Industrial Construction With Aluminum Windows 0
Steel beam: Commonly used welded composite steel beams consist of an I-shaped section consisting of upper and lower flange plates and webs. The main material is Q235B or Q345B.
Easy Install Steel Structure Warehouse For Industrial Construction With Aluminum Windows 1
 Wind- resistant column: The wind-resistant column is the structural component of the gable wall. The function of the wind-resistant column is mainly to transmit the wind load of the gable wall. The upper part is transmitted to the entire steel frame structure through the connection with the steel beam, and the lower part is transmitted to the foundation through the connection with the foundation. The main material It is Q235B or Q345B.
Easy Install Steel Structure Warehouse For Industrial Construction With Aluminum Windows 2
 Crane beam: The beam used to install the crane track is called the crane beam, which is generally installed on the upper part of the factory building.
Easy Install Steel Structure Warehouse For Industrial Construction With Aluminum Windows 3

Features:

  • Product Name: Steel Structure Warehouse
  • Column: Hot Rolled/Welded H-Section Steel
  • Material: Q355B/ Q235B Steel
  • Windows: Aluminum/PVC
  • Type: Warehouse
  • Size: Customized
  • Warehouse Building System
  • Steel Storage Warehouse
  • High Strength Steel Structure


Technical Parameters:

Product NameSteel Structure Warehouse
TypeWarehouse
MaterialQ355B/ Q235B Steel
SurfacePainted/ Galvanized
SizeCustomized
WallSandwich Panel/ Color Steel Sheet
RoofSlope/ Flat
WindowsAluminum/ PVC
DoorsRoller Shutter/ Swing/ Sliding
PurlinC/Z-Section Steel
BeamHot Rolled/ Welded H-Section Steel
Steel Structure Warehouse Technical Parameters
Product NameSteel Structure Warehouse
TypeWarehouse
MaterialQ355B/ Q235B Steel
SurfacePainted/ Galvanized
SizeCustomized
WallSandwich Panel/ Color Steel Sheet
RoofSlope/ Flat
WindowsAluminum/ PVC
DoorsRoller Shutter/ Swing/ Sliding
PurlinC/Z-Section Steel
BeamHot Rolled/ Welded H-Section Steel


Applications:

The Steel Structure Warehouse is suitable for a wide range of applications, including:

  • Industrial storage facilities
  • Manufacturing plants
  • Distribution centers
  • Logistics warehouses
  • Commercial storage facilities
Scenarios

A Steel Structure Warehouse can be used in various scenarios, such as:

  • Expanding an existing warehouse: The flexible design of the Steel Structure Warehouse allows for easy expansion, making it an ideal solution for businesses looking to increase their storage capacity.
  • Setting up a new warehouse: The quick construction time and cost-effective nature of the Steel Structure Warehouse make it a popular choice for businesses setting up new storage facilities.
  • Temporary storage needs: The Steel Structure Warehouse can be easily disassembled and relocated, making it a great option for temporary storage needs.
Easy Install Steel Structure Warehouse For Industrial Construction With Aluminum Windows 4

Important Factors Affecting Warehouse Steel Structure Price

Raw Material
Fluctuations in the price of steel have an important impact on the price of steel structure buildings. The increase in steel prices will directly cause the overall price of steel structure buildings to rise. The different section sizes, steel grade, thickness of the wall, and roof will cause the difference in price. So the raw materials are the main factor that affected the cost of steel workshop building.
External Load
External loads include wind load, snow load, dead load, and live load. Structural engineers calculate the steel structure based on the external load. If the load is large, the amount of steel used in the structure will increase.

The Span Of The Steel Frame
The larger span of the steel frame, the greater the amount of steel used per steel frame. More than 30 meters is considered a large width. If the steel frame has a large span and no center pillar, the amount of steel used will increase.

Structure
For steel structure buildings with cranes or mezzanine floors, to ensure the safe operation of cranes, steel columns will be increased, and columns of an equal cross-section will be adopted, which will increase the amount of steel used in the building.

Design Factor
Reasonable steel structure design can save raw materials and affect the cost of the steel structure workshop. Design plan is an essential factor for influencing the quantity of steel, directly affecting the total structural steel cost.

Packing and Shipping:

Easy Install Steel Structure Warehouse For Industrial Construction With Aluminum Windows 5
